Exhaust fans Axial roof-mount Direct Drive Upblast Propeller Fan
R-ARPUD
R-ARPUD

Direct DRive Upblast Propeller Fan

(R-ARPUD)

Axial Direct Drive Fans are the perfect low cost exhaust choice in the areas that have little or no ductwork, and thus, relatively low to moderate resistance.

  • Air Volume: 1 – 80,000 cfm
  • Maximum SP: 2" wg. @ standard air density
Contact Sales Rep

Features

  1. Fan construction G90 galvanized steel
  2. Wind band channels provide lateral rigidity
  3. Aluminum butterfly dampers
  4. Water gutter to drain water and melting snow and ice
  5. Steel or Aluminum Propellers
  6. Non-overloading design for safe operation
  7. Precision balanced for smooth vibration free operation
  8. Removable wind band and shaft wrapper
  9. Integrated 4 point lifting lugs
  10. Disconnect Switch

Options

  1. Roof curb
  2. Base with access door
  3. Outlet guard
  4. Magnetic butterfly damper latch
  5. UL793
  6. Heat and Smoke option

Certifications

Models R-ARPUD-20 thru R-ARPUD-72 are ETL Listed under file number 102628244PRT-001 and comply with UL705 (electrical) Standards and CSA Std C22.2, No 113.

Catalog #110R

September 2017

Resources

Models

  1. RPUD-20-MS20" Up-blast Direct Drive Roof Prop Fan (Steel Prop)
  2. RPUD-24-A24" Up-blast Direct Drive Roof Prop Fan (Aluminum Prop)
  3. RPUD-24-MS24" Up-blast Direct Drive Roof Prop Fan (Steel Prop)
  4. RPUD-30-A30" Up-blast Direct Drive Roof Prop Fan (Aluminum Prop)
  5. RPUD-30-X30" Up-blast Direct Drive Roof Prop Fan (Steel Prop)
  6. RPUD-36-A36" Up-blast Direct Drive Roof Prop Fan (Aluminum Prop)
  7. RPUD-36-X36" Up-blast Direct Drive Roof Prop Fan (Steel Prop)
  8. RPUD-42-A42" Up-blast Direct Drive Roof Prop Fan (Aluminum Prop)
  9. RPUD-42-X42" Up-blast Direct Drive Roof Prop Fan (Steel Prop)
  10. RPUD-48-A48" Up-blast Direct Drive Roof Prop Fan (Aluminum Prop)
  11. RPUD-48-X48" Up-blast Direct Drive Roof Prop Fan (Steel Prop)
  12. RPUD-54-A54" Up-blast Direct Drive Roof Prop Fan (Aluminum Prop)
  13. RPUD-54-X54" Up-blast Direct Drive Roof Prop Fan (Steel Prop)
  14. RPUD-60-A60" Up-blast Direct Drive Roof Prop Fan (Aluminum Prop)
  15. RPUD-60-X60" Up-blast Direct Drive Roof Prop Fan (Steel Prop)
  16. RPUD-72-A72" Up-blast Direct Drive Roof Prop Fan (Aluminum Prop)
  17. RPUD-72-X72" Up-blast Direct Drive Roof Prop Fan (Steel Prop)
